The 502 oxygen degreased brass full bore ball valve with long thread and large flat bearing for shutting off oxygen, argon or nitrogen systems (not suitable for acetylene).
| Specification | Value |
|---|---|
| DN inches NPS | 3/8'' |
| DN metric | 12/17 |
| Brand | AIRAGA |
| Direct mounting | Yes |
| Thread standard | ISO 228-1 |
| Stem sealing material | PTFE Gland packing + EPDM O-ring |
| Type of coating | Nickel-plated |
| Opening device | Handle |
| Application | Industry |
| Shaft/stem matérial | Brass CW614N |
| DN | DN10 - 3/8'' |
| Face to Face (mm) | 51.5 |
| Fluid | Oxygen / Argon / Nitrogen |
| Body material | Brass CW617N |
| Number of ways | 2 |
| Bore | Full |
| Packing gland | Yes |
| PS (bar) | 60 |
| Connections | BSP MM |
| Seats | PTFE |
| Ball material | Chrome-plated brass CW617N |
| TS max (°C) | 120 |
| TS min (°C) | -20 |
| Warranty period | 2 years |
| Handle material | Carbon steel |
| Handle type | White lever |
If you have any questions about this product, please feel free to contact us.
| Product Name | Product Number | EVAC Number | Price | Add to Cart |
|---|---|---|---|---|
| BSP MM Brass CW617N Full 3/8'' White lever | 502003 | S1010000 |
€6.27
(excl. btw)
|
add to cart |
| BSP MM Brass CW617N Full 1/2'' White lever | 502004 | S1010001 |
€10.23
(excl. btw)
|
add to cart |
| BSP MM Brass CW617N Full 3/4'' White lever | 502005 | S1010002 |
€14.51
(excl. btw)
|
add to cart |
| BSP MM Brass CW617N Full 1'' White lever | 502006 | S1010003 |
€23.79
(excl. btw)
|
add to cart |
| BSP MM Brass CW617N Full 1''1/4 White lever | 502007 | S1010004 |
€34.74
(excl. btw)
|
add to cart |
| BSP MM Brass CW617N Full 1''1/2 White lever | 502008 | S1010005 |
€46.49
(excl. btw)
|
add to cart |
| BSP MM Brass CW617N Full 2'' White lever | 502009 | S1010006 |
€76.86
(excl. btw)
|
add to cart |
| BSP MM Brass CW617N Full 3/8'' White butterfly handle | 502013 | S1010007 |
€6.27
(excl. btw)
|
add to cart |
| BSP MM Brass CW617N Full 1/2'' White butterfly handle | 502014 | S1010008 |
€10.23
(excl. btw)
|
add to cart |
| BSP MM Brass CW617N Full 3/4'' White butterfly handle | 502015 | S1010009 |
€14.51
(excl. btw)
|
add to cart |
| BSP MM Brass CW617N Full 1'' White butterfly handle | 502016 | S1010010 |
€23.79
(excl. btw)
|
add to cart |
